The two techniques that which are used for designing a database from the system requirement are
1.ER Modelling (Top Down approach)
2.Normalization (Bottom Up approach)
Note:
Specialization (Top Down approach) is always applied on single entities
Generalization (Bottom Up approach) is always applied to the group of entities
ER Modelling [Top down approach]:
ER-Models are originally proposed by peter in 1976 ,to unify the network and the relational database that are being used.
ER-Model is a conceptual data model that views the real world as entities and relation ships.
Entity: An entity is an object whose information is stored in the database it has an independent existence to collect the data.
Entities are classified as dependent/independent (or) strong/weak
Entity Set: An Entity Set is a set of entities of some type that share the same properties.
Relationship: A relationship represent an association between two (or) more entities they are classified as
Degree of Relationship :
1.Unary Relationship
2.Binary Relationship
3.Ternary Relationship
Relationship Constraints:
1.Cardinality Ratio.
2. Participation Constraints
Entity: An entity
is anything (a person, a place, a thing, or an event) about which data are to be collected and stored.
An entity represents a particular type of object in the real world. Entity occurrence is unique and distinct.
Ex: customer, student, employee etc…
Types of Entity:
Strong Entity:
Strong entity
are
those
entity
types
which
has
a
key
attribute.
The primary
key helps in identifying each entity uniquely.
It is represented by a rectangle. In the above example, Roll_no
identifies each element
of the table uniquely and hence, we can say that STUDENT
is a strong entity type.
Weak Entity:
Weak entity type doesn't
have a key attribute. Weak entity type can't be identified on its own. It depends upon some other strong entity
for its distinct identity. A weak entity
is represented by a double
outlined rectangle.
Attributes: Attributes describe the behavior as the properties of an entity that which are associated, different types of attributes are
1.Simple Attribute
2 Composite Attribute
3.Single value attribute
4.Multi valued Attributes
5.Derived attribute
1.Simple Attribute: It is an attribute composed of single component with an independent existence. These are atomic attributes that which cannot be further sub divided
Example:
2.Composite Attribute: An attribute composed of multiple components each with an independent existence is called composite attribute
Example:
3.Single valued Attributes: A single value attribute is that which holds a single value for a single entity
Example 1:
Example 2:
4.Multi valued Attributes: The attribute that which holds multiple values for a single entity
Example:
5.Derived attribute :A derived attribute represents a values that is derived from a value of a related attributes (or) set of attributes where some attributes are related for a particular entity
Example:
Symbols used in Entity Relationship diagrams:
Steps in designing ER diagram
Step1:Identify the entities that which are required for developing a project
Step2:Identify the key attributes for every entity and other relevant attributes
Step3:Find the relationship among the entities
Step4:Now draw the complete ER diagram with all attributes including the key attributes
Example 1:
ER Diagram for Hospital Management System:
Example 2:
ER-diagram for university management System Database:
Step1: Using MS-Access
Create the data base for the below ERD diagram with four entity (patient, doctor, nurse and ward)using MS-Access database as shown
Entity 1:
patientpat_id | pat_name | pat_disease |
---|
101 | raju | tb |
102 | rani | cancer |
103 | kani | fever |
104 | vani | cough |
105 | dhoni | typhoid |
doctordoc_id | doc_name | pat_id |
---|
201 | rk | 101 |
202 | pk | 102 |
203 | ck | 103 |
204 | dk | 104 |
205 | sk | 105 |
Entity 3:
nurse
n_id | ward_id | pat_id |
---|
301 | 401 | 101 |
302 | 402 | 102 |
303 | 403 | 103 |
304 | 404 | 104 |
305 | 405 | 105 |
Entity 4:
wardward_id | pat_id |
---|
401 | 101 |
402 | 102 |
403 | 103 |
404 | 104 |
405 | 105 |
Entity Relationship for Hospital Management System :
Step1: Using MS-Visio
Draw the ERD as shown in fig using MS Visio
click on file menu -> new -> Software and Database -> Database Model Diagram
Now draw the ERD Diagram as shown in MS-Visiopatient entity
doctor entity
ward entity
Now we shall establish hospital management system using the above four entity relations using the relationship component as shown
click on Data menu bar -> Link Data to Shapes and then select Microsoft Access Database which will be as shown
Step 4:
Now patient entity database created in the ms access will be on to your ms visio as shown
Step 5:
Repeat the same procedure for the remaining entities database (doctor, nurse and ward) created in the ms access will be on to your ms visio as shown
How to run the query in MS-Visio 2007 : To run the query in MS-Visio we need to create a query in MS-Access as follows
Click on Create menu bar -> Query Design
Step 7: Now add all the entity on to the query wizard
Step 8: Now write your query using the sql view by clicking on design menu bar -> View
Queries:
1. select * from patient where pat_disease='tb';
2. select * from patient where pat_name like 'r%';
3. select * from patient where pat_id=105;
4. select * from patient where pat_name like '%i';
5. select * from doctor where doc_name like '%k';
